Central locking control for CITROËN, PEUGEOT and other Stellantis models
Part description
Used central locking control bearing the part numbers 9817042977 and 98170429ZD is designed to operate the vehicle’s locks. When replacing a non-functional or mechanically damaged control, it offers a practical way to retain the original control layout.
The documentation lists the Citroën Berlingo K9, FIAT DOBLO III, OPEL COMBO E K9, PEUGEOT RIFTER and Toyota ProAce City models. When selecting a part, compare in particular the original part number, connector, shape and mounting points. The model name alone is not enough to determine whether the part has the matching design.
Technical information
- Manufacturer: not specified; the documentation lists Stellantis / CITROEN / PEUGEOT.
- Model: Citroën Berlingo K9; FIAT DOBLO III; OPEL COMBO E K9; PEUGEOT RIFTER; Toyota ProAce City.
- Other numbers: not specified.
- Part type: central locking control.
- Category: electrical components – other controls and switches.
- Condition: used car part.
Product codes
- Product codes: 9817042977, 98170429ZD.
Both part numbers are listed for this product. Before replacing the part, compare them with the number on the removed control and also take its design into account.
Installation recommendations
The following procedure generally applies to this type of electrical control. The exact location and method of access and removal depend on the specific model and vehicle configuration. Follow the manufacturer’s service procedure; these details are not provided in the documentation.
1) Before installation
- Compare the part numbers, dimensions, front face, mounting points and connector shape, including the contact arrangement.
- Inspect the used control: the plastic housing must not have damage that could prevent it from being secured, and the contacts must not be bent or corroded.
- Make sure the control does not stick and shows no obvious mechanical damage.
- Also check the vehicle connector and wiring before replacement. The locking problem may not be caused by the control itself.
2) Required tools and materials
- Plastic trim removal levers.
- Hand tools suitable for the actual fasteners.
- A flashlight, clean cloth and protection for surrounding visible surfaces.
- If needed, a product intended for electrical contacts and suitable for the surrounding materials.
3) Step-by-step installation procedure
- Secure the vehicle against movement and prepare access to the work area.
- Keep the key outside the vehicle and ensure you can access the interior in case it is unexpectedly locked.
- Switch off the ignition and electrical accessories. Follow the manufacturer’s procedure for allowing the electronics to go to sleep and safely disconnecting the battery before working on electrical connectors.
- Inspect how the surrounding trim is secured. Release covers only at the designated points; do not force them off.
- Once the control is accessible, note its orientation and the wiring route, for example by taking a photograph.
- Release the control’s fasteners using the appropriate tool and carefully slide it out without pulling on the wires.
- Release the connector lock and disconnect it by pulling on its housing, not the wires.
- Compare the two controls side by side. If the connector or mounting points differ, do not proceed by modifying the connector or plastic parts.
- Inspect the vehicle connector and accessible wiring. Remove any dirt using a suitable method; have damaged or loose contacts professionally repaired first.
- Connect the replacement control, secure the connector and fit the part into its original mount. The wiring must not be trapped or stretched.
- Refit the trim and fasteners. Restore the power supply according to the manufacturer’s procedure and check that the control works.
4) Post-installation checks and function verification
- With the vehicle stationary, check that the central locking responds to each control command, as applicable to the vehicle’s equipment.
- Check that the control is firmly secured, does not stick and that the surrounding trim sits correctly.
- Keep the key outside the interior being locked during testing. Consider the risk of accidental locking before testing.
- If the fault persists, continue by diagnosing the power supply, wiring and central locking system rather than repeatedly replacing the control without diagnosis.
- A stationary test is usually sufficient for a basic check of this type of control; carry out any further checks in accordance with the vehicle’s service instructions.
5) Common installation mistakes and how to avoid them
- Choosing based on appearance alone: also compare the part numbers, connector and mounting points.
- Breaking plastic clips: first determine how to release them and use suitable removal tools.
- Pulling on the wires: disconnect the connector by its housing only, after releasing the lock.
- Connector not fully engaged or wiring trapped: check that the connector is secured and the wires are routed freely before refitting the trim.
- Confusing a system fault with a faulty control: rule out visible damage to the connector and wiring before installation.
Reasons why the part may become damaged
The following are general causes of damage that may affect central locking controls. They do not describe faults identified on this specific item.
- Mechanical wear from frequent use, which may lead to unreliable switching or the control sticking.
- Excessive pressure or impact, which may damage the button, cover or mounting clips.
- Ingress of liquids and dirt, which may cause poor contact, corrosion or restrict button movement.
- Rough removal, especially prying with an unsuitable tool or pulling on connected wires.
- Loose or damaged connector, which may cause intermittent operation and place strain on the electrical connection.
